1： Equip many kinds of screw and pressure ring,can adjust according to different raw materials ,reach to the best extrusion .
2 ：3 kinds of discharge:die hole,template and annular space ,can make different shapes .
3 ：Screw and pressure ring adopt wearproof alloy precision casting .
4 ：Feeder adopt varying pitch screw ,isn’t easy to make pimple ,uniformity discharge .
5 ：Feeder adopt transducer to drive ,easy to adjust the feed capacity .
6 ：Paddle conditioner ,good mixing efficience, long modulation time(30-60s)
7 ：Double stainless steel heat retaining conditioner
8 ：The machine runs stably
9 ：Import NSK bearings
1: After extrusion ,the urease Active parameter values of soybean is UA≤0.2
2: After extrusion ,the starch degree of gelatinization of the corn is over 95%
3 :After extrusion ,the cottonseed cake detoxification is over 92%
4 :After extrusion ,the rice bran will be kep fresh
5 :After extrusion ,the pig food can prevent the piglet having loose bowels ,enhance palatability .
|
Model |
Main power (kw) |
Feeder power (kw) |
Cutter power (kw) |
Conditioner power (kw) |
Capacity (T/H ) |
|
EXT135 |
22 |
0.75 |
--- |
--- |
0.1-0.2 |
|
EXT165 |
55/75 |
1.5 |
5.5 |
5.5 |
0.5-1.8 |
|
EXT190 |
90/110 |
1.5 |
11 |
11 |
1.5-3 |
|
EXT235 |
250/315 |
2.2 |
22 |
22 |
6-12 |
|
EXT138 |
500/630 |
3 |
22*2 |
22*2 |
12-18 |
|
EXT158 |
630/800 |
4 |
37*2 |
37*2 |
20-25 |
|
AFE145 |
90/110 |
1.5 |
11 |
11 |
1-3 |
|
AFE175 |
132/160 |
2.2 |
15 |
15 |
3-5 |
