1. Screw adopts modular structure, single and double thread can be combined freely;
2. The design of split screw enables quick and easy recovery after unfortunate blockage, convenient to dismounting;
3. The screw sleeve is supported by an adjustable suspension system which allows the machine to be opened and reassembled without loss of alignment.;
4. The screw sleeve is supported by an adjustable suspension system which allows the machine to be opened and reassembled without loss of alignment.;
5. Dry puffing process, adopts self-heating method, no need steam system, is more aligned with user’s actual needs.
2. The design of split screw enables quick and easy recovery after unfortunate blockage, convenient to dismounting;
3. The screw sleeve is supported by an adjustable suspension system which allows the machine to be opened and reassembled without loss of alignment.;
4. The screw sleeve is supported by an adjustable suspension system which allows the machine to be opened and reassembled without loss of alignment.;
5. Dry puffing process, adopts self-heating method, no need steam system, is more aligned with user’s actual needs.
| Model | Power（kw） | Overall dimensions (mm) | Main shaft speed (r/min) | Diameter (mm) | Capacity(t/h) |
| 9PK-60 | 15 | 650*900*1140 | 500 | Ø60 | 100-120 |
| 9PK-95 | 30 | 2157*1200*1710 | 580 | Ø95 | 200-300 |
| 9PK-135 | 75 | 2150*1600*1730 | 600 | Ø135 | 800-1100 |
