1. Use special balance approach, to ensure the fully balance of inertia force of every direction during the motor process of sifter planar;
2. Use flexible support in the tail, has the characteristic of small vibration and lower noisy;
3. The materials movement track are respectively circular, elliptic and reciprocal rectilinear motion in the former, middle and back of the screen machine, so it has the features of large capacity and high efficiency;
4. Equipped with self-cleaning device avoids mesh clogging;
5. Fully enclosed structure, avoid the dust out leakage, protect working environment.
2. Use flexible support in the tail, has the characteristic of small vibration and lower noisy;
3. The materials movement track are respectively circular, elliptic and reciprocal rectilinear motion in the former, middle and back of the screen machine, so it has the features of large capacity and high efficiency;
4. Equipped with self-cleaning device avoids mesh clogging;
5. Fully enclosed structure, avoid the dust out leakage, protect working environment.
| Model | SFJH80x2C | SFJH100x2C | SFJH120x2C | |
| Screen length*width（mm） | 1600×800 | 2140×1000 | 2500×1200 | |
| Layer | 2 | 2 | 2 | |
| Screen angle(°) | 4-5° | 4-5° | 4-5° | |
| Turning radius(mm) | 30 | 30 | 40 | |
| Eccentric shaft speed(r.p.m) | 264 | 264 | 218 | |
| Power(kw) | 1.5 | 1.5 | 4 | |
| Capacity (t/h) | Powder | 5-7 | 8-10 | 12-16 |
| Granule | 8-12 | 12-18 | 18-25 | |
| Overall dimension(mm) | 1250x2580X1076 | 3210x1440x1076 | 4230x1820x1164 | |
| Weight（kg） | 700 | 850 | 1800 | |
